This machine is suitable for the material crushing by the industries of pharmaceutics, chemical, and foodstuff etc.
Working Method :
This machine uses the relative movement between the active fluted disc and the fixed fluted disc to impact, grind and crush the target materials. The size of granules can be achieved by changing of the screen.
Technical Paramerters :
Model
Capacity (kg/h)
Size of input granules(mesh)
Size of output granules(mesh)
Speed of principal axis (rpm)
Overall Size (LxWxH)
Weight (kg)
CTC-20B
60-150
<6
20-250
4500
600×600×1660
280
CTC-30B
100-300
<10
20-250
3800
700×700×1660
340
CTC-40B
150-600
<10
20-250
2500
800×800×1800
450
CTC-60B
200-1200
<10
20-250
1600
950×950×2100
600
